- Wiring Harness
- Custom Specialized wiring harness
- Charger
- Custom charger, 42V4A w/ Rosenberger plug, 100-240V
- Motor
- Specialized 2.2 Custom Rx Trail Tuned Motor, 90Nm Torque, 565W Power
- Battery
- Specialized M3-700, Integrated battery, 700Wh
- UI/Remote
- Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote
- Seat Binder
- Alloy, 38.6mm
- Frame
- FACT 11m full carbon, 29" front wheel, 27.5" rear wheel, full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel, geo adjust head tube, geo adjust horst pivot
- Fork
- 2023_22, 38, K, FLOAT, 29in, F-S, 160, Grip 2, HSC, LSC, HSR, LSR, Shiny Blk, CQV M701S Over SBC K13 Nearly Black Gloss/SBC K01 Logo, Kabolt-X 110, BLK, 1.5 T, 58HT, 44mm Rake, N/M OE;2023_22, 38, K, FLOAT, 29in, F-S, 160, Grip 2, HSC, LSC, HSR, LSR, Shiny Blk, YS-728 Matte_Stealth/YS-728 Matte_Stealth Logo, Kabolt-X 110, BLK, 1.5 T, 58HT, 44mm Rake, N/M OE
- Rear Shock
- Fox Float X2 Factory, Kashima, 210x55mm
- Rear Brake
- SRAM Code Stealth Ultimate, 4-piston caliper, hydraulic disc, 220mm rotor
- Front Brake
- SRAM Code Stealth Ultimate, 4-piston caliper, hydraulic disc, 220mm rotor
- Crankset
- Praxis Carbon/Custom Offset/ISIS Spindle Interface, 160mm
- Shift Levers
- SRAM XX Eagle Transmission Cassette, 12spd, 10-52t
- Chainrings
- New SL 1.2 spider, 104BCD w/SRAM 32t Transmission compatible alloy ring
- Cassette
- RockShox Reverb AXS, 30.9, 1X remote, (S1:100mm, S2: 125mm, S3: 150mm, S4-S6: 170mm)
- Rear Derailleur
- SRAM XX Eagle Transmission Derailleur
- Chain
- SRAM XX Eagle Transmission Flattop Chain
- Front Tire
- Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6"
- Rear Tire
- Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
- Rear Wheel
- Roval Traverse SL 27.5, 148mm spacing, XD freehub body
- Front Wheel
- Roval Traverse SL 29
- Inner Tubes
- Standard, Presta Valve
- Saddle
- Bridge, 155/143mm, Hollow Ti-rails
- Grips
- Deity Lockjaw, Lock On, 32mm OD, 133mm Length, Black
- Stem
- Deity, 35.0mm
- SeatPost
- RockShox Reverb AXS, 30.9, 1X remote, (S2: 125mm, S3: 150mm, S4-S6: 170mm)
- Handlebars
- Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm, 35.0mm
- SWAT
- SWAT CC steerer tube integrated tool with chain tool and link
- Pedals
- TEST RIDE PEDALS PROVIDED BY SPECIALIZED
- Weight
- 22.5kg (49 lb, 9.7 oz)
- Weight Size
- S4
Geometry
| S2 | S3 | S4 | S5 | S6 | |
|---|---|---|---|---|---|
| Crank Length | 160 | 160 | 160 | 160 | 160 |
| Handlebar Width | 780 | 780 | 780 | 780 | 780 |
| Stem Length | 35 | 35 | 35 | 50 | 50 |
| Saddle Width | 155 | 143 | 143 | 143 | 143 |
| Seatpost Length | 125 | 150 | 170 | 170 | 170 |
| Stack | 617 | 626 | 635 | 644 | 653 |
| Reach | 432 | 452 | 477 | 502 | 532 |
| Headtube Length | 105 | 115 | 125 | 135 | 145 |
| Headtube Angle | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 |
| BB Height | 350 | 350 | 350 | 350 | 350 |
| BB Drop | 27 | 27 | 27 | 27 | 27 |
| Trail | 130 | 130 | 130 | 130 | 130 |
| Fork Length (full) | 567 | 567 | 567 | 567 | 567 |
| Fork Rake/Offset | 44 | 44 | 44 | 44 | 44 |
| Front Center | 760 | 784 | 814 | 843 | 878 |
| Chainstay Length | 442 | 442 | 442 | 442 | 442 |
| Wheelbase | 1200 | 1225 | 1255 | 1284 | 1318 |
| Bike Standover Height | 776 | 783 | 787 | 788 | 790 |
| Seat Tube Length | 390 | 405 | 425 | 445 | 465 |
| Seat Tube Angle | 77.2 | 76.7 | 76.2 | 76.2 | 76.2 |
| Max Seatpost Insertion | 220 | 240 | 255 | 275 | 295 |
| Min Seatpost Insertion | 80 | 80 | 80 | 80 | 80 |
