Detail Information

The RIVAL 1 XPLR AXS Power Meter Crankset will boost the performance and looks for any adventurous bike build and provide the equipment needed to track the progression of a riders training. A power meter integrated into the bottom bracket spindle senses power output through the left side crank arm, and on the drive-side crank arm is a single X-SYNC chainring with a narrow/wide tooth profile that strongly meshes up with the chain, reducing the risk of dropping the chain when putting the power down over technical terrain. Sculpted and skeletonized aluminium crank arms and SRAM's proven DUB bottom bracket spindle provide incredible efficiency and power transfer to the rest of the drivetrain; the wider spacing of the crank arms clear the rear triangle of gravel bikes/frames and will even have enough clearance to be able to be installed on some hardtail mountain bikes. Finally, an industrial look plus a wide range of crank arm lengths round out the features on a lightweight and rugged set of cranks that are ready for bike rides to points unknown.

Features:

• Sculpted and skeletonized aluminium crank arms concentrate material where it is needed for strength and stiffness, while eliminating unnecessary material for lighter weight and attractive looks
• 29mm diameter alloy DUB bottom bracket spindle adds durability, reduces weight, improves stiffness, and simplifies installation (bottom bracket cups and bearings are not included)
• Spindle-based power meter unit is highly weather resistant (IPX7 waterproof rating) and is powered by a replaceable AAA lithium battery that will last up to 400 hours to be able to power through a full riding season
• X-SYNC chainring technology with narrow/wide tooth profile positively engages with the chain and reduces the chances of dropping the chain over rough terrain
• Multiple crank arm length options are available to optimize the biomechanical fit and performance of the bicycle
• Compatible with most gravel and even some hardtail mountain bikes and frames with 135mm through 148mm rear hub spacing

Specifications:

• Intended Discipline: Road & Gravel
• Spindle Diameter: 29mm (SRAM DUB)
• Bottom Bracket Included: No
• Pedal Spindle: 9/16"
• Chainrings Included: Yes
• Chainring BCD: -
• Chainring Mount: SRAM Direct Mount (8-Bolt)
• Chainline: 47.5mm
• Drive Type: 1x
• Speed Compatibility: 12 Speed | 13 Speed
• Chainring Material: Aluminium
• Crankarm Material: Aluminium
• Colour: Black
