Frameset
- Seat Binder
- Alloy, 38.6mm
- Frame
- M5 alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
- SWAT
- SWAT 4.0 internal downtube storage
Suspension
- Fork
- FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset S1:150mm of travel, S2-S6:160mm of travel
- Rear Shock
- FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment, 210x55mm
Brakes
- Front Brake
- SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 200mm rotor
- Rear Brake
- SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 200mm rotor
Drivetrain
- Cassette
- SRAM 12-speed,10-52t
- Chain
- SRAM 70 Transmission 12-Speed Flattop Chain
- Bottom Bracket
- SRAM DUB Threaded Wide
- Shift Levers
- SRAM Eagle 70
- Rear Derailleur
- SRAM Eagle 70 Transmission, 12-speed, easy shift under load
- Crankset
- SRAM Eagle 70, 165/170mm, 55mm chainline, 32T
Wheels & tires
- Front Tire
- Butcher, GRID TRAIL casing, Gripton T9 compound, TLR, 29X2.4
- Spokes
- DT Swiss Elemental
- Rear Tire
- Eliminator, GRID TRAIL casing, Gripton T7 compound, TLR, S1-S2: 27.5x2.4, S3- S6: 29x2.4"
- Front Hub
- Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28h
- Rear Hub
- Specialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12X148mm thru-axle, 32h, HG Steel Fhb
- Rims
- Specialized, hookless alloy, 30mm inner width, tubeless ready
- Inner Tubes
- Standard, Presta Valve
Cockpit
- Stem
- Alloy Trail Stem, 35mm bar bore
- Saddle
- Bridge Comp, Hollow Cr-mo rails 155/143
- Grips
- Specialized Trail Grips
- Handlebars
- Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S6: 800 width, 50mm rise
- Seatpost
- Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm
Product details
- Product ID
- 263530
Weight
- Weight
- 16.69 kg (36 lb, 12.7 oz)
- Weight Size
- S4
Geometry
| S1 | S2 | S3 | S4 | S5 | S6 | |
|---|---|---|---|---|---|---|
| Crank Length | 165 | 165 | 165 | 170 | 170 | 170 |
| Handlebar Width | 780 | 780 | 800 | 800 | 800 | 800 |
| Stem Length | 40 | 40 | 40 | 40 | 40 | 40 |
| Saddle Width | 155 | 155 | 143 | 143 | 143 | 143 |
| Seatpost Length | 125 | 150 | 170 | 200 | 200 | 230 |
| Stack | 611 | 621 | 630 | 644 | 658 | 671 |
| Reach | 400 | 420 | 445 | 470 | 495 | 525 |
| Headtube Length | 95 | 100 | 110 | 125 | 140 | 155 |
| Headtube Angle | 64 | 64 | 64 | 64 | 64 | 64 |
| BB Height | 337 | 340 | 340 | 340 | 340 | 340 |
| BB Drop | 38 | 35 | 35 | 35 | 35 | 35 |
| Trail | 133 | 134 | 134 | 134 | 134 | 134 |
| Fork Length (full) | 561 | 573 | 573 | 573 | 573 | 573 |
| Fork Rake/Offset | 44 | 44 | 44 | 44 | 44 | 44 |
| Front Center | 724 | 755 | 785 | 816 | 848 | 884 |
| Chainstay Length | 430 | 432 | 435 | 435 | 445 | 445 |
| Wheelbase | 1153 | 1186 | 1217 | 1249 | 1290 | 1327 |
| Top-tube Length (horizontal) | 542 | 574 | 596 | 625 | 649 | 678 |
| Bike Standover Height | 738 | 751 | 745 | 745 | 745 | 751 |
| Seat Tube Length | 385 | 385 | 405 | 425 | 445 | 465 |
| Seat Tube Angle | 77.7 | 76.5 | 76.5 | 76 | 76 | 76 |
| Saddle Height for Effective ST Angle | 645 | 690 | 735 | 780 | 825 | 870 |
| Max Seatpost Insertion | 245 | 245 | 255 | 255 | 285 | 285 |
| Min Seatpost Insertion | 80 | 80 | 80 | 80 | 80 | 80 |
