- Frame
- Specialized A1SL Premium Aluminum, Fitness Geometry, butted tubing, internal cable routing, flat-mount disc, quick-release, Plug + Play rack/fender mounts
- Fork
- Specialized FACT 9r Carbon Monocoque, flat-mount disc, 12x100mm thru-axle, low rider mounts, Plug + Play fender mounts, Future Shock 1.5
- Front Brake
- Shimano BR-MT200, hydraulic disc, 160mm
- Rear Brake
- Shimano BR-MT200, hydraulic disc, 160mm
- Shift Levers
- Shimano CUES SL-U6000, 11-Speed
- Rear Derailleur
- Shimano CUES 11-speed w/ Shadow Plus
- Cassette
- Shimano CUES CS-LG400-11, 11-speed, 11-50t
- Crankset
- Prowheel Alloy, XXS - XS: 165mm, S - M: 170mm, L - XL: 175mm, 42t
- Chainrings
- Narrow Wide Steel 42T
- Bottom Bracket
- Threaded BSA 68mm, 24mm spindle
- Chain
- KMC eGlide for 11-Speed CUES
- Rims
- 700C disc, double-wall alloy, 22mm depth, 21mm internal width, 32h
- Front Hub
- Alloy, sealed cartridge bearings, Center Lock, 12x100mm thru-axle, 24h
- Rear Hub
- Alloy, Center lock Disc, High-Low Flange, Sealed Cartridge Bearing, 32H, 12mm Axle, 142mm Spacing
- Spokes
- Stainless, 14g
- Front Tire
- Pathfinder Wirebead Fast Gravel 700X40C
- Rear Tire
- Pathfinder Wirebead Fast Gravel 700X40C
- Inner Tubes
- Standard 40mm SV 700x32-50
- Handlebars
- Alloy Mini Rise, 9-degree backsweep, 15mm rise, 31.8mm
- Stem
- Future Stem, Comp
- Grip
- Specialized Neutralizer, Body Geometry, locking grip
- Saddle
- Body Geometry Power Sport, steel rails
- SeatPost
- Alloy, 2-bolt, 14mm offset, 27.2mm
- Seat Binder
- Bolt-type, 31.8mm
- Pedals
- Specialized, platform
- Product ID
- 222059
- Weight
- Weight Size
- LG
Geometry
| XXS | XS | S | M | L | XL | |
|---|---|---|---|---|---|---|
| Crank Length | 165 | 165 | 170 | 170 | 175 | 175 |
| Handlebar Width | 680 | 680 | 680 | 680 | 680 | 680 |
| Stem Length | 60 | 60 | 70 | 80 | 90 | 100 |
| Saddle Width | 155 | 155 | 155 | 143 | 143 | 143 |
| Seatpost Length | 300 | 300 | 350 | 350 | 400 | 400 |
| Stack | 587 | 590 | 606 | 635 | 651 | 672 |
| Reach | 355 | 371 | 376 | 382 | 386 | 398 |
| Head-Tube Length | 111 | 125 | 143 | 169 | 186 | 208 |
| Head-Tube Angle | 69.5 | 70 | 70 | 71 | 71 | 71 |
| B-B Height | 284 | 284 | 284 | 284 | 284 | 284 |
| B-B Drop | 70 | 70 | 70 | 70 | 70 | 70 |
| Trail | 78 | 75 | 75 | 68 | 68 | 68 |
| Fork Length (full) | 395 | 395 | 395 | 395 | 395 | 395 |
| Fork Rake/Offset | 51 | 51 | 51 | 51 | 51 | 51 |
| Front-Center | 602 | 618 | 629 | 634 | 644 | 663 |
| Chain-Stay Length | 440 | 440 | 440 | 440 | 440 | 440 |
| Wheelbase | 1074 | 1093 | 1033 | 1049 | 1060 | 1065 |
| Top-Tube Length (horizontal) | 529 | 549 | 559 | 573 | 581 | 599 |
| Bike Stand-Over Height | 700 | 722 | 750 | 778 | 810 | 831 |
| Seat-Tube Length | 360 | 395 | 440 | 470 | 510 | 530 |
| Seat-Tube Angle | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
