- Frame
- Specialized A1 Premium Aluminum, Fitness Geometry, butted tubing, internal cable routing, flat-mount disc, quick-release, Plug + Play rack/fender mounts
- Fork
- A1 Premium Aluminum, flat-mount disc, Plug + Play fender mounts, low rider rack mounts, quick-release
- Front Brake
- Tektro HD-R280, hydraulic disc, resin pads, flat-mount, 160mm
- Rear Brake
- Tektro HD-R280, hydraulic disc, resin pads, flat-mount, 140mm
- Shift Levers
- Shimano Cues 10-Speed Rapidfire Plus, W/ OPTICAL GEAR DISPLAY, SL-U6000-10R
- Rear Derailleur
- Shimano Cues 11-speed w/ Shadow Plus
- Cassette
- Shimano Cues 10-Speed, 11-48T, CS-LG300-10
- Crankset
- Prowheel Alloy, XXS - XS: 165mm, S - M: 170mm, L - XL: 175mm
- Chainrings
- Narrow Wide Steel 42T
- Bottom Bracket
- BB68+, BSA24, 68mm
- Chain
- KMC eGlide for 11-Speed Cues
- Rims
- 700C disc, double-wall alloy, 22mm depth, 21mm internal width, 32h
- Front Hub
- Alloy, 6-bolt disc, loose ball bearing, quick-release, 32h
- Rear Hub
- Alloy, 6-bolt disc, 8-/9-speed freehub, loose ball bearing, quick-release, 32h
- Spokes
- Stainless, 14g
- Front Tire
- Pathfinder Wirebead Fast Gravel 700X40C
- Rear Tire
- Pathfinder Wirebead Fast Gravel 700X40C
- Inner Tubes
- Presta, 700X32-50mm
- Handlebars
- Alloy Mini Rise, 9-degree backsweep, 15mm rise, 31.8mm
- Stem
- 3D-forged alloy, 31.8mm, 7-degree rise
- Grip
- Specialized Neutralizer, Body Geometry, locking grip
- Saddle
- Bridge Sport, Steel rails, 155/143mm
- SeatPost
- Alloy, 12mm offset, 2-bolt clamp, 27.2mm
- Seat Binder
- Bolt-type, 31.8mm
- Pedals
- Specialized, platform
- Product ID
- 293705
- Weight
- 11.07 kg (24 lb, 6.5 oz)
- Weight Size
- LG
Geometry
| XXS | XS | S | M | L | XL | |
|---|---|---|---|---|---|---|
| Crank Length | 165 | 165 | 170 | 170 | 175 | 175 |
| Handlebar Width | 680 | 680 | 680 | 680 | 680 | 680 |
| Stem Length | 60 | 60 | 70 | 80 | 90 | 100 |
| Saddle Width | 155 | 155 | 155 | 143 | 143 | 143 |
| Seatpost Length | 300 | 300 | 350 | 350 | 400 | 400 |
| Stack | 536 | 555 | 563 | 593 | 608 | 633 |
| Reach | 393 | 398 | 402 | 414 | 373 | 388 |
| Head-Tube Length | 121 | 139 | 147 | 175 | 191 | 217 |
| Head-Tube Angle | 69.5 | 70 | 70 | 71 | 71 | 71 |
| B-B Height | 288 | 288 | 288 | 288 | 288 | 288 |
| B-B Drop | 70 | 70 | 70 | 70 | 70 | 70 |
| Trail | 79 | 76 | 76 | 69 | 69 | 69 |
| Fork Length (full) | 395 | 395 | 395 | 395 | 395 | 395 |
| Fork Rake/Offset | 51 | 51 | 51 | 51 | 51 | 51 |
| Front-Center | 606 | 623 | 631 | 636 | 645 | 665 |
| Chain-Stay Length | 440 | 440 | 440 | 440 | 440 | 440 |
| Wheelbase | 1036 | 1053 | 1061 | 1067 | 1076 | 1096 |
| Top-Tube Length (horizontal) | 532 | 552 | 560 | 574 | 582 | 602 |
| Bike Stand-Over Height | 702 | 725 | 755 | 785 | 815 | 837 |
| Seat-Tube Length | 360 | 395 | 440 | 470 | 510 | 530 |
| Seat-Tube Angle | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
