- Frame
- Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
- Seat Binder
- Alloy, quick release, 34.9
- Fork
- SR Suntour XCE 26/27.5/29, 28mm stanchions, coil spring, QR, 80/90/100mm travel (size-specific), 42mm offset
- Front Brake
- Tektro HD-M280, 2-piston caliper, hydrailic disc
- Rear Brake
- Tektro HD-M280, 2-piston caliper, hydrailic disc
- Front Derailleur
- Shimano Altus 2-speed
- Rear Derailleur
- Shimano Altus, 9-speed
- Shift Levers
- Shimano Altus, RapidFire Plus, 9-speed
- Cassette
- SunRace, 9-Speed, 11-36t
- Chain
- KMC X9EPT, 9-speed, anti-corrosion coating w/ reusable Missing Link™
- Crankset
- Stout 2x, forged alloy
- Bottom Bracket
- Square-tapered, 73mm, internal bearings, 122.5mm spindle
- Rims
- Specialized alloy, disc only, double-wall, 25mm inner width, 32h
- Front Hub
- Alloy, Sealed bearing, 6-Bolt, disc, 100x9mm spacing, quick-release
- Rear Hub
- Alloy Sealed bearing, 6-Bolt, disc, 135x9mm spacing, quick-release
- Spokes
- Stainless, 14g
- Front Tire
- Ground Control 2BR, 650B/29x2.35, T5
- Rear Tire
- Ground Control 2BR, 650B/29x2.35, T5
- Inner Tubes
- Standard, Schrader Valve
- Stem
- Stout 3D-forged alloy, 31.8mm, 6-degree rise
- Handlebars
- Alloy Mini Rise, 9-degree backsweep, 15mm rise, 31.8mm
- Grips
- Specialized Trail Grips, lock-on
- Saddle
- Bridge Sport, Steel rails, 155/143mm
- SeatPost
- Alloy, 2-bolt clamp, 30.9mm
- Pedals
- Specialized, platform
- Product ID
- 279922
- Weight
- 14.1 kg (31 lb, 1.4 oz)
- Weight Size
- MD
Geometry
| XXS - 26 | |
|---|---|
| Crank Length | 160 |
| Handlebar Width | 700 |
| Stem Length | 35 |
| Saddle Width | 143 |
| Seatpost Length | 300 |
| Wheel Size | 26 |
| Stack | 543 |
| Reach | 355 |
| Head-Tube Length | 95 |
| Head-Tube Angle | 68 |
| B-B Height | 310 |
| B-B Drop | 44 |
| Trail | 94 |
| Fork Length (full) | 455 |
| Fork Rake/Offset | 46 |
| Front-Center | 601 |
| Chain-Stay Length | 420 |
| Wheelbase | 1017 |
| Top-Tube Length (horizontal) | 516 |
| Bike Stand-Over Height | 781 |
| Seat-Tube Length | 310 |
| Seat-Tube Angle | 73.5 |
