- Fork
- A1 Premium Butted Alloy, Alloy steerer, 15x110 mm, W/Mini Fender
- Frame
- A1 Premium Butted Alloy, unisex frame, internal cable routing, 148mm thru-axle, 30.9mm dropper post ready, replaceable derailleur hanger compatible
- Seat Binder
- Bolt-type, 34.9mm
- Rear Brake
- Promax DSK-926, Hydraulic Disc Brake, 160mm Rotor, Adjustable Reach
- Front Brake
- Promax DSK-926, Hydraulic Disc Brake, Adjustable Reach
- Chainrings
- 40T
- Crankset
- Forged Alloy, 115mm length, narrow Q-factor, w/ chainguard
- Chain
- KMC X9EPT, 9-speed, anti-corrosion coating w/ reusable Missing Link™
- Bottom Bracket
- Square-tapered, 68mm
- Shift Levers
- microSHIFT Advent SL-M6190, 9-speed , short reach triggers for easy operation
- Rear Derailleur
- microSHIFT Advent, 1x9 w/ clutch
- Cassette
- microSHIFT Advent, 9-speed, 11-42t
- Rims
- Alloy, 16mm depth, 25mm internal width, 28H
- Rear Hub
- Alloy, 6-Bolt, 28H, 12x148 Boost, 11-speed compatiable
- Front Hub
- Alloy, 6-Bolt, 28H, 15x110 Boost
- Front Tire
- Kicker Wirebead 24X2.1
- Rear Tire
- Kicker Wirebead 24X2.1
- Inner Tubes
- Presta, 32mm valve
- Spokes
- Stainless, 14g
- Saddle
- Bridge Kids Saddle, 130mm
- Handlebars
- Double Butted Alloy, 40mm rise , 11deg back sweep, 2.5deg up seep, 31.8mm, 620mm
- Grips
- Specialized Trail Grips, lock-on
- SeatPost
- Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
- Stem
- Stout 3D-forged alloy, 31.8mm, 6-degree rise
- Pedals
- Nylon platform w/ reflectors
Geometry
| 24 | |
|---|---|
| Crank Length | 140 |
| Handlebar Width | Dia:22.2 |
| Stem Length | 35 |
| Saddle Width | 130 |
| Seatpost Length | 250 height 0000179387 |
| Stack | 449 |
| Reach | 350 |
| Head-Tube Length | 95 |
| Head-Tube Angle | 68 |
| B-B Height | 287.5 |
| B-B Drop | 30 |
| Trail | 83 |
| Fork Length (full) | 370 |
| Fork Rake/Offset | 42 |
| Front-Center | 565 |
| Chain-Stay Length | 390 |
| Wheelbase | 953 |
| Top-Tube Length (horizontal) | 479 |
| Bike Stand-Over Height | 593 |
| Seat-Tube Length | 310 |
| Seat-Tube Angle | 73.5 |
