Frameset
- Frame
- Specialized A1 Premium Aluminum, 1" threaded headset
- Fork
- Formed steel tubes, 95mm Spacing
- Seat Binder
- Bolt-type, 25.4mm
Wheels & tires
- Rims
- 12" alloy, 16mm depth, 21mm internal width
- Front Hub
- Bolt-on, 95mm spacing, loose ball bearings, 16h
- Rear Hub
- Bolt-on, 95mm spacing, loose ball bearings, 16h
- Spokes
- Stainless, 14g
- Front Tire
- Rhythm Lite Airless, 12x2.3
- Rear Tire
- Rhythm Lite Airless, 12x2.3
Cockpit
- Stem
- Die Cast Aluminum, 35mm length, 22.2 clamp diameter
- Handlebars
- Steel, 400mm width, 20mm rise, 8-degree backsweep
- Grips
- Specialized, slip-on
- Saddle
- Hotwalk Integrated Saddle/Seatpost
- SeatPost
- Steel, 22.2mm
Product details
- Product ID
- 222028
Weight
- Weight Size
- One Size
- Weight
- 4.1 kg (9 lb, 0.6 oz)
Geometry
| 12 | |
|---|---|
| Handlebar Width | Dia: 22.2 |
| Stem Length | 35 |
| Saddle Width | 110 |
| Seatpost Length | L: 230 |
| Stack | 319 |
| Reach | 185 |
| Head-Tube Length | 70 |
| Head-Tube Angle | 69 |
| B-B Height | 118 |
| B-B Drop | 55 |
| Trail | 57 |
| Fork Length (full) | 205 |
| Fork Rake/Offset | 5 |
| Front-Center | 297 |
| Chain-Stay Length | 258 |
| Wheelbase | 544 |
| Top-Tube Length (horizontal) | 295 |
| Bike Stand-Over Height | 281 |
| Seat-Tube Length | 160 |
| Seat-Tube Angle | 71 |
