Home Crux Pro Satin Carbon / Deep Lake Metallic / Smoke / White Sage Metallic

Specialized

Crux Pro Satin Carbon / Deep Lake Metallic / Smoke / White Sage Metallic

| Be the first to review
$11,200.00 $9,999.00
AfterPay

Pay for your purchase in four interest-free installments (due every two weeks).

Call to Order Select Location
Add to comparison list

Detail Information

The Crux is the lightest gravel bike in the world, with the exceptional capability of massive tire clearance and performance gravel geometry. It’s not just the ultimate expression of gravel performance, it’s your one-way ticket to gravel enlightenment.

This Crux Pro comes spec'd with a accurate and quick-shifting SRAM Force eTap AXS hydraulic disc groupset, lightweight and durable Roval Terra CL Disc wheels, and 2Bliss Ready, 700x38mm Pathfinder Pro tires that hookup over nasty terrain."

  • Lightest: 725g S-Works 12r and 825g 10r frames. We took the revolutionary breakthroughs that made Aethos the lightest bike ever and applied them to the Crux. The result? A gravel bike that climbs like a dream, floats over nightmarish terrain, and weighs less than a full bottle in your cage.
  • Capable: 47c/650b x 2.1” tire clearance. More clearance means more capability. With Diverge-level tire clearance, Crux takes you anywhere you can imagine, at full gas.
  • Responsive: Nimble, supple, and reactive. Responsive at the pedals. Supple in the saddle. With performance gravel geometry and race-influenced fit inspired by Crux’s iconic history in ‘cross.

Technical Specifications


Frameset
Frame
Crux FACT 10r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout
Suspension
Fork
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Brakes
Front Brake
SRAM Force eTap AXS
Rear Brake
SRAM Force eTap AXS
Drivetrain
Chain
SRAM Force 12-speed
Cassette
SRAM XPLR, XG-1251, 12-speed, 10-44t
Bottom Bracket
SRAM DUB BSA 68
Shift Levers
SRAM Force eTap AXS
Crankset
SRAM Force 1x
Rear Derailleur
SRAM Force XPLR eTap AXS
Chainrings
40t
Wheels & tires
Inner Tubes
700x28/38mm, 48mm Presta valve
Front Tire
Pathfinder Pro 2BR, Tan Sidewall, 700x38
Rear Tire
Pathfinder Pro 2BR, Tan Sidewall, 700x38
Front Wheel
Roval Terra CL, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes
Rear Wheel
Roval Terra CL, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes
Cockpit
SeatPost
Roval Terra Carbon Seat Post, 20mm Offset
Handlebars
Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare
Saddle
Power Pro with Mirror
Seat Binder
Specialized Alloy, 30mm
Stem
Specialized Pro SL, alloy, 4-bolt, 6-degree rise
Tape
Supacaz Super Sticky Kush
Product details
Product ID
223481
Weight
Weight Size
56
Weight
7.63kg (16 lb, 13.1 oz)



Geometry


  49 52 54 56 58 61
Crank Length 165 170 172.5 172.5 175 175
Handlebar Width 380 400 420 420 440 440
Stem Length 70 80 90 100 110 110
Saddle Width 155 155 143 143 143 143
Seatpost Length 330 330 330 380 380 380
Stack 530 547 560 578 598 621
Reach 375 382 388 397 405 415
Head Tube Length 100 115 130 147 167 190
Head Tube Angle 70.5 71.25 71.5 72 72.25 72.5
BB Height 284 284 286 286 286 286
BB Drop 74 74 72 72 72 72
Trail 74 69 67 64 62 60
Fork Length, Full 401 401 401 401 401 401
Fork Rake/Offset 50 50 50 50 50 50
Front Center 594 600 608 618 630 644
Chainstay Length 425 425 425 425 425 425
Wheelbase 1008 1014 1023 1033 1045 1059
Top Tube Length, Horizontal 512 539 549 568 582 599
Bike Standover Height 749 772 794 816 841 866
Seat Tube Length 466 496 521 546 576 606
Seat Tube Angle 75.5 74 74 73.5 73.5 73.5
